Colt Prototype "Zig-Zag" Root 1855 Revolvers
Percussion Revolvers
•
6m 58s
The 1855 “Root” pocket revolver was a reasonably successful design for the Colt company, although it was not the best mechanical design. The side hammer design used the cylinder axis to rotate and lock in place instead of using the rear face of the cylinder, which resulted in several small and delicate parts. In an effort to correct these deficiencies, Colt and his factory superintendent Elisha Root experimented with a “zig-zag” design as well, which would use and external cam running in grooves on the cylinder wall to rotate and lock it. Root received a patent (#13,999) for a system using a ring trigger and lug on the bottom of the frame, and these two prototype revolvers demonstrate a similar system with the lug on the top of the frame. This system was not ultimately adopted, and these remain just an interesting look into the experimental workings of the Colt company.
